• Power Supply:
Input: AC 100-240V, 50/60 Hz, 18W Output: DC 15V, 1.2A
• Frequency: 1MHz (±10%)
• Mode: 3 levels (Low, Medium, High)
• Time: 5, 10 or 15 minutes with auto turn off
• Power Output: (0.5W/cm2
(Low), 0.8W/cm2
(Medium), 1.2W/cm2
(High)
• Duty Factor: 20% (Low), 33% (Medium), 50% (High)
• RBN : ≤8.0
• Rated Output Power: 9.6W (±20%)
• Effective Intensity: 2.4W/cm2
(±20%)
• AER : 4 cm2
• Beam Type: Collimated
• Modulation Wave Shape: Pulsed
• Operating Conditions:
Temperature: 5-40°C Humidity: 30-75%RH Air Pressure: 700-1060hPa
• Service Life of Device: 3 Years*
• Applied Part: Treatment Head
• IP Classification System: IP22
* Period of time specified by the manufacturer during which the device is expected to remain safe for use.
